MINI & MOKE REAR BRAKE WHEEL CYLINDER 5/8″ – PROTEX [P5095]

PRODUCT OVERVIEW

Rear 5/8″ brake wheel cylinder to suit disc brake Mini and Moke applications.

The 5/8″ rear wheel cylinder was commonly used from 1959-1967 on vehicles fitted with front disc brakes, helping reduce rear brake activity and maintain better brake balance. This is important on Minis and Mokes, as incorrect rear wheel cylinder sizing can affect braking performance and make the rear brakes too aggressive.

A worn, leaking or seized rear wheel cylinder can cause poor braking, fluid loss, uneven rear brake operation or difficulty bleeding the brakes. Replacing tired wheel cylinders is an important part of keeping the rear brake system safe and reliable.

SPECIFICATIONS

• Suits: Disc brake Mini and Moke models
• Common fitment: 1959-1967 disc brake front-end applications
• Position: Rear
• Application: Rear brake wheel cylinder
• Bore size: 5/8″ / approximately 15.9mm
• Brand: Protex
• Kit includes: 1 x 5/8″ wheel cylinder
• Kit includes: 1 x bleed nipple
• Kit includes: 1 x retaining clip
• Sold: Individually
• Alternative part numbers: [GWC1101AP], [4412], [P5095]
• 1 required per rear wheel
• 2 required per vehicle

IMPORTANT FITMENT NOTE

The best way to confirm the correct wheel cylinder is to remove the old cylinder and measure the bore size before ordering. This wheel cylinder has a 5/8″ bore, which is approximately 15.9mm.

We strongly recommend replacing rear wheel cylinders in pairs. If one side is worn or leaking, the other side is usually the same age and may also be close to failure.

IMPORTANT SAFETY NOTE

Brake components are safety-critical. Wheel cylinders should be fitted by a qualified automotive mechanic. After installation, the brake system must be correctly bled, checked for leaks, adjusted and tested before road use.
